ATA WTX-6V1 Genuine Wall Button Remote

About the ATA WTX-6V1 Genuine Wall Button Remote

The wireless part is what makes it useful. A conventional wall button is wired to the opener, so it lives wherever the cable was run, usually beside the garage door and nowhere else. This one transmits like a remote, so it mounts anywhere within range: inside the house door to the garage, at the top of the internal stairs, beside the front entry, or at a second position in a long garage. Adding a control point costs a screwdriver rather than a day of chasing cable through a wall cavity.

Four buttons means four doors, or a combination of doors and gates. Each is coded separately to its own receiver, so a house with a roller door, a tilt door and a driveway gate can run all three from one plate by the back door.

It suits ATA openers on the TrioCode system. That covers the whole GDO-9 family, meaning the Dynamo and Enduro, the GDO-9v2S2, the GDO-9v2 and the GDO-9v3, plus the EasyRoller from the GDO-6 through to the GDO-6v4, both SecuraLift versions of the GDO-7, the Shed Master GDO-8v3 ASM, the Toro GDO-10v1, the GDO-11v1 and GDO-11v3, the NeoSlider NES-24v1 and NES-24v3, the DCB-05 Dual Gate Controller and the Elite SGO-1. It does not work with the blue case PTX-4 on 433 MHz, nor with motors from the SecuraCode or 27 MHz TX eras, although a TrioCode receiver card will bring those across if you would rather keep the motor you have.

The plate is white with grey buttons and a red indicator light, measuring roughly 7.34 cm wide, 11.59 cm long and 1.56 cm deep, so it sits close to the wall and reads as a light switch rather than a piece of equipment.

Power is a CR2032 3V coin cell, fitted before dispatch, and the compartment needs a tool to open. Because a wall button is pressed far more often than a car remote, the battery is the first thing to check when it becomes unreliable. Coin cells are hazardous if swallowed, so keep new and used cells away from children and dispose of them at a battery recycling point.

We also stock the ATA WTX-6V1 Genuine Wall Button Remote To Suit Dominator as a separate listing. If your motor is a Dominator, or you are replacing a wall button that is already on the wall and want to match it, look at that one first, and call us on 1300 736 683 if you are not sure which of the two applies to your situation.

Allgate installs, programs and services ATA equipment right across Sydney, and adding a second control point is one of the quicker jobs a technician can fold into a service visit.

If you are replacing a wired wall button that has failed, leave the old plate and its cabling where they are rather than pulling them out. It costs nothing to leave in place and it keeps the option of a wired control at that position open for whoever owns the property next.

Product details

Brand

ATA

Type

Genuine part

Category

Wall buttons

Battery

CR2032 3V

Allgate stock code

AG_ATA86220

Warning: contains a coin battery

Coin batteries are dangerous. A swallowed or inserted coin battery can cause serious injury or death within two hours.

This product is supplied with a CR2032 3V coin battery.

• Keep new and used batteries out of reach of children at all times
• Do not use this product if the battery compartment does not close securely. Stop using it and keep it away from children
• Dispose of used batteries immediately and safely. A flat battery is still dangerous
• Never swallow a battery or place one inside any part of the body. It can cause severe internal chemical burns

If you think a battery has been swallowed or placed inside any part of the body, seek immediate medical attention. Call the Poisons Information Centre on 13 11 26 or go straight to your nearest hospital emergency department.

Delivery, returns and fitting

Shipping costs and delivery times are shown beside the Add to cart button above. Unused parts can be returned by post within 30 days of purchase for a full refund, with return postage paid by you. Your rights under the Australian Consumer Law apply on top of that, so if the part you receive turns out not to suit your opener, call us before you program it and we will work out what does. Our full terms of sale are set out on the Allgate terms and conditions page.

Most customers fit and code a new part themselves in a few minutes using the instructions supplied. If you would rather have it done, an Allgate technician can program and test it on site anywhere we work, which is every suburb listed on the Sydney service areas page.

Not sure the ATA WTX-6V1 Genuine Wall Button Remote is the right part?

Buying the wrong remote is the most common mistake we see, and it is almost always avoidable with one photograph. Send a clear shot of the front and the back of your existing unit, plus one of the motor if you can reach it safely, to service@allgate.com.au and our team will tell you exactly which part suits your opener. If you would rather talk it through, our domestic line is 1300 736 683, Monday to Friday 8am to 4pm. Commercial and strata customers can reach a technician on 1300 655 600 at any hour, on any day.

You can also search the catalogue by the model number printed on your existing handset, which is the fastest way to find the match yourself.
